Snorkel ML18C Material Lift

Snorkel ML18C Material Lift
Snorkel ML24C Material Lift
Snorkel ML12C Material Lift

Snorkel ML18C Material Lift

The Snorkel ML18C construction material lift is durable for heavy-duty applications. A class-leading load capacity makes easy work of material lifting. Quick-fold stabilizers offer secure lifting, and aluminum construction ensures a long working life.

Standard Features:

  • Stabilisers with non-marking swivel casters (ML18C & ML24C)
  • Mast brake
  • Cable guard
  • Non-marking transport/loading wheels
  • Dual-handle, two-speed shift-on-the-fly winch
  • Metal cable pulleys with sealed bearings
  • Heavy-gauge aluminium extrusions
  • Heavy duty, non-marking casters
  • Crane attachment point
  • 2 year parts & labour, 5 year structural warranty
  • CE approved

Download Snorkel ML18C Material Lift

Specifications Overview

Max Lift Height (m)

5.6

Stowed Width (m)

0.77

Stowed Height (m)

2.2

Load Capacity (kg)

318

Description

Snorkel ML18C Material Lift

The Snorkel ML18C construction material lift is durable for heavy-duty applications. A class-leading load capacity makes easy work of material lifting. Quick-fold stabilizers offer secure lifting, and aluminum construction ensures a long working life.

Standard Features:

  • Stabilisers with non-marking swivel casters (ML18C & ML24C)
  • Mast brake
  • Cable guard
  • Non-marking transport/loading wheels
  • Dual-handle, two-speed shift-on-the-fly winch
  • Metal cable pulleys with sealed bearings
  • Heavy-gauge aluminium extrusions
  • Heavy duty, non-marking casters
  • Crane attachment point
  • 2 year parts & labour, 5 year structural warranty
  • CE approved

Additional information

Lift Height - forks up (m)

5.6

Lift Height - forks down (m)

5.1

Stabiliser Width (m)

1.63

Operating Length (m)

1.86

Fork Width - outside- (m)

0.58

Fork Length (m)

0.76

Ground Clearance (mm)

60

Max. load capacity (0.36m load centre) (kg)

318

Max. load capacity (0.61m load centre) (kg)

200

Max. load capacity (1.07m load centre) (kg)

84

Min. load height (mm)

150

Winch - high speed (cranks/m)

13.1

Winch - low speed (cranks/m)

49.2
