Genie Z34/22N

Category:

Description

Genie Z34/22N

  • Another narrow base with zero tail-swing boom.
  • Ideal for confined work spaces-the Z-34/22N is only 1.47 m (58 in) wide and has zero tail-swing.
  • Rolls through standard double doorways. Works both indoors and outdoors with emission free, noise free electric drive.
  • 180 degree rotation and powered platform for easy operation and precise platform positioning.
  • The Sep-Ex motor controller eliminates the need for forward/reverse contractors or speed sensors reduces complexity and improves the reliability of the drive system.
  • The Sep-Ex drive motors and controller provide automatic hill braking and ramp braking.
  • Dual parallelogram riser design allows ascent and descent along a vertical plane without retracting or extending the boom.





    * required fields

    Specification

    Download Genie Z34/22 Cherry Picker Specifications

    Makes

    New/Used

    Working Height (m)

    12.52
    Platform Height (m)

    10.52
    Outreach

    6.78
    Basket Capacity

    227
    Stowed Length (m)

    5.71
    Width (m)

    1.47
    Stowed Height (m)

    2
    Weight (kg)

    5214
    Power Source

    Battery
