Genie Z30/20N RJ

Genie Z30/20N RJ

Category:

Description

Genie Z30/20N RJ

  • Works in tight spaces with zero tail-swing and front arm swing in stowed and raised positions
  • 47 in (1.19 m) wide chassis for narrow aisle access
  • 4 ft (1.22 m) jib boom has 139 degree range of motion allowing positioning above or below horizontal
  • Z-30/20 N RJ optional rotating jib offers 200 degrees of horizontal rotation
  • Standard self-leveling platform features 180 degrees powered horizontal rotation for precise positioning and easy operation
  • Drive performance of 35% gradeability and 3.3 mph travel speed
  • Motor controller eliminates the need for forward/reverse contactors or speed sensors, reducing complexity and improving reliability
  • Automatic hill and ramp braking





    * required fields

    Specification

    We are currently uploading specification documents for all units, please fill out the enquiry form and we are happy to send one to you directly via email

    Makes

    New/Used

    Working Height (m)

    10.89
    Platform Height (m)

    8.89
    Outreach

    6.25
    Basket Capacity

    227
    Stowed Length (m)

    5.31
    Width (m)

    1.19
    Stowed Height (m)

    2
    Weight (kg)

    6622
    Power Source

    Battery
